| Magnetic TTL: |
Power +5 VDC +/-10%
(50mV ripple maximum).
Ground 0 VDC (GND).
Chassis
ground connected to GND and magnetic head
case.
|
| Operating Current: |
15mA maximum for
undecoded magnetic stripe only (3 tracks), TTL.
35mA
additional for decoded with keyboard or RS-232
interface.
5.5mA typical with LED (<8mA at peak usage)
for port-powered model.
|
| External Power Supply: |
5 VDC/350mA (required
for RS-232 version only).
Port-powered option requires no
power supply.
|
 |
| Operating Temperature: |
32°F to 131°F (0°C to
55°C ). |
| Storage Temperature: |
-22°F to 158°F (-30°C
to 70°C ). |
| Humidity: |
Maximum 95%
non-condensing. |
 |
| Electronics MTBF: |
Read electronics,
magnetic: 125,000 POH..
Interface electronics,
RS-232/keyboard: 125,000 POH.
|
| Magnetic Head Life: |
1,000,000 passes
minimum.
|
| Rail
and Cover Life: |
1,000,000 passes
minimum.
|
| Read
Rate: |
Less than one error in
100,000 bits on cards conforming to ISO 7811 1-5 (not induced
by operator error).
|
| Warranty: |
One year, parts and
labor.
|
 |
| Magnetic Stripe Formats: |
ISO 7811, AAMVA, and CA
DMV.
|
| Swipe
Speed: |
3 to 55 inches per
second, bi-directional. (5 to 50 inches per second for
port-powered model.)
|
| Card
Width: |
.01 to .055
inches.
|
| Slot
Width: |
Maximum card thickness:
.055 (1.37mm).
|
| Indicators: |
Tri-colored LED, beeper
(not available on port-powered model).
|
| Interfaces: |
RS-232, Keyboard wedge,
USB/keyboard, TTL (undecoded magnetics). Port-powered option
is RS-232 only. |
| Dimensions: |
Length: 3.54 inches
(90mm). Width: 1.34 inches (34mm).
Height: 1.10 inches
(28mm). |
| Weight: |
Approximately 4.6
oz.
|
| Cable
Length: |
6-foot straight cable.
(Cable exit through the bottom of the unit is available as an
option; minimum quantities apply.)
|
| Connector: |
Keyboard: Combination 5
pin/6 pin DIN.
TTL: 9 pin squeeze. RS-232:
DB9F.
|
| MiniMag Swipe Reader Footprint: |
Click
here to enlarge...  |
